HV Series

HV Series

The HV Series of rugged customizable ASCII hand held terminals is ideal for cost-sensitive HMI applications. Nearly every aspect of operation can be changed using simple menu selections or direct host control.

The HV Series terminals have four function keys that you can define as characters or strings. For applications requiring warning signals or key indication, the HV Series has optional LED indicators, located within each key on the top row, and programmable tones.

  • Low Cost, Rugged Handheld Terminal
  • Menu-Programmable Function Keys
  • ANSI Models Available
  • Three Year Warranty
  • LED Indicators and Backlit Keypad Available
HV Series in Use

Why use Two Technologies for your next purpose-built HMI project?

In today’s competitive environment, businesses need to react quickly to ever changing industry demands. Two Technologies can transform your requirements into reality with purpose-built HMIs.

Partnering with Two Technologies allows you to utilize our years of experience and know-how in the design and manufacture of durable HMI products built to your specific needs allowing you a faster time-to-market at a competitive price.

  • Low minimum quantity
  • Quick turn customization
  • Custom firmware
  • Custom overlays, logo tags, and case modifications
  • Durable, high quality products
  • 3-year warranty
  • Long term support
  • A history of collaboration since 1987
  • In-house design

Customization Options


Description
Option
Standard
Available
Available
Available
Description
Option
RS-232
Available
RS-422
Available
CMOS/TTL
Available
Description
Option
5.0 Volts DC ±5%
Available
7.5 to 12 Volt DC
Available
9.5 to 28 Volts DC
Available
Description
Option
20-Key Membrane
ANSI Model Only
40-Key Elastomeric
Available
30-Key or 40-Key Membrane
Available
30-Key or 40-Key Backlit
Available
Custom Keypads & Keypad Graphics
Available
Description
Option
LED Indicators
Available
VT-100 ANSI 3.64 Compatibility
Available

  • Elastomeric: These keypads provides a great look and excellent tactile feel. Epoxy caps make this keypad extremely resistant to wear and suitable for all environments, except where petroleum-based chemicals (oil) are present.
  • Membrane: Best used when working in harsh conditions where chemical, dirt and liquids may be present.
  • Backlit: LEDs, which can be powered on and off, are positioned behind the keycaps to illuminate them when needed.
20-Key Membrane

20-Key
Membrane

30-Key Membrane

30-Key
Membrane

40-Key Membrane

40-Key
Membrane

40-Key Elastomeric

40-Key
Elastomeric

7-Foot Extended Coiled Cables
Part Number
Modular to Modular, Black
1210-7-BK
Modular to Modular, Gray
1210-7
Modular to Modular, Non-reversing, Gray
1210-7-NR
Modular to Stripped Leads, Black (1210-HD)
10172
15-Foot Extended Cables
Part Number
Modular to Modular, Black
1210-15-BK
Modular to Modular, Gray
1210-15
Permanent Connection Cable
Part Number
7-Foot with 6-Pin Modular Termination
Suffix-PW
15-Foot with 6-Pin Modular Termination
Suffix-PW15
7-Foot with DB-25P, DB-25S, DE-9S, DE-9P, or DA-15 Termination*
Suffix-PW
15-Foot with DB-25P, DB-25S, DE-9S, DE-9P, or DA-15 Termination*
Suffix-PW
* Wiring configuration must be provided; set up charges and minimums may apply.
Note: Permanent wire cables are not available with battery powered units.
Modular to "D" Connector Kits
Part Number
Modular to DE-9P
1270-M-KIT
Modular to DE-9S
1270-F-KIT
Modular to DB-25P
1280-M-KIT
Modular to DB-25S
1280-F-KIT
Connector-Modular Socket (8-Inch Stripped and Tinned)
623k
Wired Adaptors with Power Socket
Part Number
Modular to DE-9S (PCAT)
91446
Modular to DB-25P (DTE)
1280-DTE
Modular to DB-25S (DCE)
1280-DCE
Power Supplies
Part Number
Power Supply
1226-1
Silicon Boots
Part Number
Yellow
14261
RTV Seal
Membrane Keypad & Display

Click on a link to view the PDF in a new window where you can download it.

To learn more about our customization option, contact Two Technologies
